FBL6000 Pro & FBL6200 Pro
- Deskripsi
Deskripsi
Seri flap barrier FBL6000 Pro dirancang untuk lingkungan dengan lalu lintas tinggi, dilengkapi flap barrier yang cepat dan responsif dengan kapasitas hingga 30 orang per menit, sehingga efektif mengurangi kemacetan.
Dibuat dengan bahan stainless steel SUS304 dan memiliki rating perlindungan IPX4, FBL6000 Pro tahan air dan tahan korosi. Selain itu, seri FBL6000 Pro dilengkapi dengan beberapa sensor inframerah, teknologi anti-jepit, dan sistem alarm akses tidak sah, sehingga menjamin keselamatan pejalan kaki setiap saat. Baik digunakan di kantor perusahaan, stasiun transit, maupun fasilitas umum, sistem ini memastikan pengalaman yang aman dan andal.
Parameter
| Specification | Details |
|---|---|
| Model Name | FBL6000 Pro / FBL6200 Pro |
| Audio Indicator | Speaker |
| Visual Indicator | LED pictograms Green arrow = normal use Red cross = door closing |
| Display | N/A |
| Lane Type | FBL6000 Pro: Single lane FBL6200 Pro: Dual flap barriers (additional lane) |
| Lane Width | 600 mm |
| Lane Height | 994 mm |
| Barrier Movement Type | Retractable flap barrier (Acrylic / optional: Tempered Glass) |
| Motor | DC brushless motor |
| Movement Speed | 0.6s – 1s |
| Movement Accuracy | 1.5° per movement |
| Clutch | N/A |
| Cabinet Material | SUS304 Stainless steel |
| Lid Material | SUS304 Stainless steel |
| IR Sensors | 5 pairs (standard), up to 9 pairs (optional) |
| Motherboard Function | System config, access mode config, anti-tailgate config |
| Motherboard Communication | Fire alarm port (Relay1), RS485 port1 |
| Controller | C3 / InBio series controller (optional), 3rd-party controller supported |
| Credential Options | RFID: ProID10 Fingerprint: FR1500S / 3rd-party QR Code: QR500 Face terminal: G4 Pro |
| Flow Rate | Face: 30/min RFID: 20/min Fingerprint: 15/min QR: 30/min |
| Accessibility | Standard lane (600 mm): adult |
| Power Supply | AC110–220, 50/60 Hz |
| Power Rating | 40W |
| Fire Signal | Input for voltage-free contact |
| Noise Level | < 60 dB |
| MCBF | > 5 million |
| Net Weight | FBL6000 Pro: 100 kg FBL6200 Pro: 70 kg |
| Gross Weight | FBL6000 Pro: 150 kg FBL6200 Pro: 90 kg |
| Dimensions (LWH) | 1414 × 300 × 994 mm (both models) |
| Dimensions w/ Packing | FBL6000 Pro: 1510 × 780 × 1230 mm FBL6200 Pro: 1510 × 400 × 1230 mm |
| Operating Temperature | -20°C to 70°C |
| Operating Humidity | 0–95% RH (non-condensing) |
| Certifications | CE, FCC |
| Ingress Protection | IPX4 |
| Supported Software | ZKBio CVAccess / ZKBio CVSecurity (depends on controller) |
| Safety Features | Power-off unlock, fire alarm door release |
| Security Features | Anti-intrusion, wrong-way alarm, auto close/lock if no passage |
| Product Delivery | Pre-assembled for easy installation |
| Application Environment | Indoor and Outdoor |
| Site Preparation | Flat/level finished floor (optional base plate for unfinished floors) |
| Security Level | Middle |
| Emergency Mode | Flap barrier unlocks automatically |
| Packing Material | Wooden Box |
