SL03-T420H
- Deskripsi
Deskripsi
SL03-T420H adalah smart lock mortise digital berbasis ZigBee yang dirancang untuk apartemen, asrama, dan sewa jangka pendek. Mengusung desain modern dengan bodi aluminium alloy dan panel kaca tempered 2.5D, kunci ini dilengkapi auxiliary latch anti-card dan deadbolt untuk keamanan fisik yang lebih kuat, serta fitur tamper-alarm melalui detektor bawaan.
Ditenagai teknologi ZigBee, kunci ini dapat dikendalikan dan dipantau dari jarak jauh secara real-time dengan konsumsi daya rendah, konektivitas stabil, dan keamanan siber lebih baik. Hal ini menjadikan SL03-T420H solusi yang lebih praktis, aman, dan efisien bagi pengelola maupun penghuni.
Parameters :
| Specification | Details |
|---|---|
| Housing Material | Aluminum Alloy |
| Color Options | Matt Black, Space Gray |
| Front Panel | Tempered Glass (2.5D edge processing), Touch keypad (12 digits) |
| Mortise Lock Type | European Standard |
| Backset | 55 mm |
| Axe Distance | 72 mm |
| Square Spindle | 7.8 mm |
| Faceplate (H×W) | 24 × 235 mm; squared standard |
| Unlocking Methods | Passcode (dynamic/periodic), Card (IC/NFC), Mobile HTML5 Links, Mechanical Key |
| Capacity | User: 100, Passcode: 100, Card: 100, Local Records: 500 |
| Card Reader | IC Card @13.56 MHz, NFC Supported (ISO/IEC 14443A) |
| Audio Prompt Language | English, Spanish |
| Indicators | Green = Access Granted Red = Verification Failed Blue = OTA Update White = Keypad Backlight |
| Wireless Communication | Zigbee 3.0 (IEEE 802.15.4) |
| Emergency Power | USB Type-C, DC 5V |
| Power Supply | 8 × AA Alkaline Batteries (not provided) |
| Battery Life | Approx. 2.5 years |
| Supported Software | ZKBio CVSecurity SmartLock |
| Door Type | Wooden Swing Door |
| Door Thickness | 35 – 60 mm (standard) |
| Opening Direction | All directions (reversible lever design) |
| Net Weight | 2.5 kg |
| Gross Weight | 3.0 kg |
| Product Dimensions (H×W×T) | Exterior: 330.9 × 75.2 × 25.3 mm Interior: 330.9 × 75.2 × 24.5 mm (*lever not included) |
| Package Dimensions (L×W×H) | 225 × 130 × 430 mm |
| Operating Temperature | -20°C to 55°C (-4°F to 131°F) |
| Operating Humidity | 10% – 90% RH (non-condensing) |
| Certifications | CE, FCC |
| Standard Functions | Unlock, Temporary Passcode (dynamic/periodic), Anti-Peeping Codes (up to 20 digits), Passage Mode, Tamper Alarm, Low Battery Alarm, Continuous Authentication Error Alarm, Firmware OTA |
| Package Contents | Exterior Assembly, Interior Assembly, Mortise Kit, IC Card × 2, Mechanical Key × 2, Studs & Screws Kit, Installation Template, Installation Guide |
