Deskripsi
VR30 dari ZKTeco menggunakan teknologi radar gelombang milimeter 79 GHz yang canggih untuk menciptakan zona keselamatan tak terlihat di bawah palang parkir, mendeteksi kendaraan dan pejalan kaki secara presisi guna mencegah kecelakaan, kerusakan properti, serta tabrakan yang merugikan.
Parameter:
| Specification | Details |
|---|---|
| Model | VR30 |
| Operating Frequency | 79GHz |
| Modulation Mode | FMCW |
| Antenna MIMO | 2T3R |
| Transmitting Power | 10 dBm |
| EIRP | 24 dBm |
| Antenna Gain | 14 dBi |
| Azimuth Field of View | ±60° (120° total) |
| Vertical Field of View | Elevation ±10° (20° total) |
| Maximum Detection Distance | 0–7 m adjustable, same for vehicle and pedestrian |
| Operating Temperature | -40°C to 85°C |
| Operating Voltage | DC 12V |
| Power Consumption | ≤1.3 W |
| Net Weight | 197 g |
| Package Dimensions (L×W×H) | 133 × 90 × 37 mm |
| Product Dimensions (L×W×H) | 118 × 78 × 19 mm |
| Online Debugging / Upgrading | Bluetooth, RS485 |
| Supported Software | Apps: ZKEasy Go OS: iOS 12+; Android 10+ |
| Ingress Protection Rating | IP67 |
| Certification | CE |
