- Deskripsi
Deskripsi
Face Depot 4A adalah terminal waktu dan kehadiran biometrik hibrid berbasis Linux yang menampilkan teknologi Pengenalan Wajah Cahaya Tampak ZKTeco yang inovatif.
Face Depot 4A menggunakan algoritme pembelajaran mendalam untuk melakukan pengenalan wajah dengan cahaya tampak dari jarak 0,3 hingga 2 meter, bahkan dalam kondisi gelap atau kurang cahaya. Selain itu, terminal meningkatkan toleransi sudut pose dan tindakan anti spoofing.
Selain itu, Face Depot 4A digabungkan dengan teknologi otentikasi biometrik Zkteco, berbagai metode verifikasi, dan konektivitas Wi-Fi / 4G serbaguna untuk memenuhi beragam kebutuhan pelanggan, menawarkan verifikasi yang akurat.
Spesifikasi :
Model | FaceDepot 4A | |
Display | 4.3″@ TFT Color Touch LED Screen (480*800) | |
Camera | Binocular Camera @ 2MP WDR | |
Operating System | Linux | |
Hardware | CPU | Quad Core@1.2GHz |
RAM | 1GB; ROM: 8GB | |
Speaker | 8 ohm @1 W | |
Supplement Light | No | |
Fingerprint Sensor | In-Glass Fingerprint | |
Model | FaceDepot 4A | |
Biometric Authentications | Fingerprint / Face / Card / Password (Virtual Keypad) | |
Fingerprint Capacity | 6,000 (1:N) (Standard) | |
User Capacity | 10,000 (1:N) (Standard) | |
Face Capacity | 6,000 (1:N) (Standard) | |
Card Capacity | 10,000 (1:N) (Optional) | |
Transaction Capacity | 100,000 (1:N) (Optional for Capacity Expansion: 200,000 ) | |
Max. User Password Length | 8 Digits | |
Biometric Verification Speed | less than 0.35 second (Facial Recognition) less than 0.5 second (Fingerprint Recognition) |
|
Touchless Biometric Recognition Distance | 30cm to 200cm @ Face | |
False Acceptance Rate (FAR) % | FAR ≤ 0.01% (Facial Recognition) FAR≤0.0001% (Fingerprint) |
|
False Rejection Rate (FRR) % | FRR ≤ 0.02% (Facial Recognition) FRR≤0.01% (Fingerprint) |
|
Biometric Algorithm | ZKFace V6.0 ZKFingerprint |
|
Card Type | ID Card@125 kHz (Optional) HID Prox@125 kHz (Optional) IC Card@13.56 MHz (Optional) Optional Multi-Tech Module: Module1: ID & IC & DESFire EV1/EV2; (125 kHz & 13.56 MHz Dual Frequency) |
|
Communication | TCP / IP*1 Wi-Fi (IEEE802.11a / b / g / n / ac) @ 2.4 GHz / 5 GHz (Coming soon) Wiegand (Input & Output)*1 RS485: ZKTeco RS485*1 USB: Type A (USB Drive Only)*1 Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm Output*1 |
|
Mobile Communication | LTE FDD: B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B13 / B18 / B19 / B20 / B25 / B26 / B28 LTE TDD: B38 / B39 / B40 / B41 UMTS: B1 / B2 / B4 / B5 / B6 / B8 / B19 GSM: B2 / B3 / B5 / B8 |
|
Standard Functions | WorkCode, ADMS, DST, T9 Keyboard (Input), Photo Capture, Event Photo Capture, 14-digit User ID, Schedule Bell, Record Query, Tamper Switch Alarm, Photo ID, Multiple Verification Methods, External Printer, HTTPs / SSH Backend Access, 12V Output |
|
Optional Functions | Wi-Fi, 4G, Backup Battery, PoE | |
Power Supply | DC 12V 3A PoE: IEEE 802.3af Backup Battery |
|
Backup Battery (Coming soon) | 2000 mAh (Lithium Battery) Max. Operating Hours: 2 Hours Max. Standby Hours: 2 Hours Charging Time: 2.5 to 3 Hours |
|
Operating Temperature | 0°C to 45°C | |
Operating Humidity | 20% to 80% RH (Non-condensing) | |
Dimensions (H*W*D) | 193.00 mm*100.00 mm*32.40 mm (L*W*H) | |
Gross Weight | 0.447 Kg | |
Net Weight | 0.402 Kg | |
Supported Software | ZKBioTime / ZKBio CVAccess (T&A Module) | |
Installation | Wall-mount | |
Certifications | ISO14001, ISO9001, CE, FCC, RoHS |
