- Deskripsi
Deskripsi
Decoder ZKTeco merupakan perangkat dekoding video jaringan beresolusi tinggi dengan teknologi canggih yang dirancang untuk menampilkan video berkualitas tinggi pada TV Wall.
Parameter:
| Specification | Details |
|---|---|
| Model | ZK-DEC-8605-4K |
| Main Processor | Multi-core embedded processor |
| Operating System | Embedded LINUX |
| Video Compression | H.265 / H.264 / MJPEG |
| Input | 1 × HDMI / Network Video Sources / Others |
| Output | 5 × HDMI Output |
| Output Resolution | 4K: 3840 × 2160 @ 50/60Hz5MP: 2592 × 1944 @ 50/60Hz4MP: 2560 × 1440 @ 50/60Hz1080P: 1920 × 1080 @ 50/60Hz720P: 1280 × 720 @ 50/60Hz |
| Audio Compression | G.711A, G.711U and AAC |
| Audio Decoding | Support |
| Decoding Resolution | Up to 8MP (4K) |
| Decoding Channel | Up to 125 channels |
| Decoding Capability | 7ch × 4K @ 30fps (HDMI 5: 3ch; HDMI 1–4: 1ch each)14ch × 5MP @ 30fps (HDMI 5: 6ch; HDMI 1–4: 2ch each)20ch × 4MP @ 30fps (HDMI 5: 8ch; HDMI 1–4: 3ch each)40ch × 2MP @ 30fps (HDMI 5: 16ch; HDMI 1–4: 6ch each)77ch × 720P @ 30fps (HDMI 5: 25ch; HDMI 1–4: 13ch each)125ch × D1 @ 30fps (HDMI 1–5: 25ch each) |
| Split Screen | 1 / 4 / 6 / 8 / 9 / 16 / 25 |
| Interoperability | ONVIF, SDK, API, RESTFUL |
| Network Interface | 2 × RJ45 interface, 10/100/1000Mbps self-adaptive |
| Serial Interface | 1 × RS232, 1 × RS485 |
| Audio Input/Output | 1 / 1 |
| Alarm Input/Output | 6 / 4 |
| USB Port | 1 × USB Port (Software recovery, system upgrade, local video files playback) |
| Reset Button | Yes |
| Power Supply | AC 100–240V, 47–63Hz |
| Power On/Off Switch | Yes |
| Power Consumption | ≤45W |
| Casing | 1U |
| Working Temperature | -10°C to 55°C / 14°F to 131°F |
| Working Humidity | 10%–90% |
| Working Pressure | Below 5000m altitude |
| Dimension (L × W × H) | 440 × 322 × 47.85 mm |
| Net Weight | ≤4.5 kg |
| Gross Weight | ≤6 kg |
